Sctrewing ware of plastic cable

Shangfeng is willing to cooperate sincerely with all customers to grow and develop together.

Sctrewing ware of plastic cable Waterproof Accessories

Material:Made from UL Nylon 66,94V-2 and tight ring from rubber.

Feature:1.Special designation,good strengthsileand none damage to electrical machine.
2.Not need to disorganization the fix terminal,cable can be inserted through directly then tighten easy and save time.

Application:Used for machinery control box,distribution plate,machine and electrical.Etc.

  • Specification
    Type Thread length L1 Entry range D1 Entry thread D2 Cable gland dimensions L-L1 Locknut thread size D3
    PG-07 8 3.5-3.6 23-8 16.5
    PG-09 8 4.5-7 10.2 25-8 21.5
    PG-11 8 5.5-10 11.5 27-8 25
    PG-13.5 9 9-13 13.5 28-9 27
    PG-16 10 10-14 16.5 30-10 30
    PG-19 10 14-18 30 10-12 28
    PG-21 11 4-18 21 38-11 37.5
    PG-25 11 18-25 25 13-18 36
    PG-29 11 18-25 27.5 42-11 47.5
    PG-36 12 25-33 34.5 43-12 58
    PG-42 13 30-38 40.5 48-13 65
    PG-48 14 37-44 45.5 48-14 70
    PG-63 27 42-50 60 13-18 36

    Type Threaded entry metric Cable rangeΦ Thread o.d.c1 Panel mounting hole Thread length C2 Sealing nutsize F Locknut size A
    MG-12 M12×1.25 7.6-4.6 12 12.5 8.5 19 18
    MG-14 M14×1.25 7.6-4.6 14 14.5 8.5 20 19
    MG-16 M16×1.5 10-6 16 16.5 15 22 22
    MG-18 M18×1.5 10-6 18 18.5 15 25 22
    MG-20 M20×1.5 14-9 20 20.5 15 27 27
    MG-24 M24×1.5 14-9 24 24.5 15 33 27
    MG-25 M25×1.5 18-13 25 25.5 15 33 33
    MG-27 M27×1.5 18-13 27 27.5 15 35 35
    MG-32 M32×1.5 25-18 32 33 15 41 41
    MG-36 M36×1.5 25-18 36 36.5 20 45 41
    MG-40 M40×1.5 30-24 40 41 20 50 50
    MG-50 M50×1.5 39-30 50 51 22 62 61
    MG-63 M63×1.5 48.5-40 63 64 25 75 75
